F18 Biometric Access Control System

F18 Biometric Access Control System Product Description

The ZKTeco F18 Biometric Access Control System is a reliable fingerprint-based security terminal designed for controlling access to offices, businesses, institutions, warehouses and other restricted areas. It combines biometric fingerprint verification with optional card authentication to provide convenient and secure employee access management.

The F18 features a ZK optical fingerprint sensor and ZK Finger V10.0 algorithm for efficient fingerprint verification. It can support up to 3,000 fingerprint templates and up to 5,000 optional ID, IC, HID Prox or HID iClass cards, depending on the installed configuration. The terminal also provides substantial transaction storage, with current ZKTeco specifications listing up to 100,000 transactions.

For connectivity, the F18 supports TCP/IP, RS232/RS485 and USB Host, while Wiegand input and output allow integration with compatible access-control equipment. It can connect to electric locks, door sensors, exit buttons, alarms and doorbells to create a complete door access solution.

Specifications

• Model: F18

• Fingerprint Capacity: 3,000

• Card Capacity: 5,000 optional

• Transaction Capacity: Up to 100,000

• Sensor: ZK Optical Sensor

• Algorithm: ZK Finger V10.0

• Display: 2.4-inch TFT LCD

• Communication: TCP/IP, RS232/RS485, USB Host

• Wiegand: Input & Output

• Power Supply: 12V DC, 3A

• Dimensions: 80 × 183 × 42 mm

• Operating Temperature: 0°C–45°C

Frequently Asked Questions 1. What is the ZKTeco F18 used for?

The F18 is used for biometric door access control and employee attendance management. It verifies users using fingerprints and, where fitted, cards.

2. How many fingerprints can the F18 store?

The F18 supports up to 3,000 fingerprint templates.

3. Does the F18 support RFID cards?

Yes. The F18 can support up to 5,000 cards using optional card configurations, including ID, IC, HID Prox and HID iClass cards depending on the installed module.
